Introducing SharkBite PEX Press
PEX Press is a press‑to‑connect piping system designed for speed, consistency, and reliability. Each fitting features a one‑piece body with a pre-attached stainless‑steel sleeve, eliminating loose parts and guesswork.
You could do a PEX press fitting in half the time that it would take to do a traditional crimp ring. It's quick and convenient, so we can get in and out of the job, efficiently and make as much money as possible.
How-to make a Press connection.
Use a PEX cutter to make a square, clean cut on the pipe. Do not use a saw or damaged tool. Uneven or angled cuts may result in improper connection. Ensure the pipe is free of burrs, debris, or damage before pressing.
Slide the SharkBite PEX Press fitting onto the pipe until it reaches the fitting shoulder. Verify full insertion by confirming the pipe is visible through the viewing windows.
Ensure the jaws are aligned squarely and fully engaged on the stainless-steel sleeve. Verify the tool’s locator ridge is positioned on the outside of the jaws, regardless of tool orientation.
Activate the tool fully until it completes the cycle and jaws are completely closed. The jaws will press the sleeve uniformly around the pipe. Do not interrupt the press cycle and do not press the connection more than once.
Verify the sleeve is evenly compressed with no gaps.Check the pressed connection using the go/no-go gauge.
How-To Video with The Lady Plumber
Discover Pex Press
More about PEX Press
Introducing: SharkBite PEX Press Fittings
Stop Leaks Fast with SharkBite PEX Press
PEX Press FAQ's
PEX Press is SharkBite’s press‑to‑connect PEX piping system that uses a pre‑attached stainless‑steel sleeve to create fast, consistent, and reliable connections.
SharkBite PEX Press fittings are compatible with both PEX‑a or PEX‑b tubing, making them versatile for new construction, service, and retrofit applications.
PEX Press fittings are designed to work with ASTM F3347 (brass) and ASTM F3348 (poly) compliant press tools. SharkBite also offers a dedicated multi‑head press tool for common sizes.
Yes. PEX Press connections can be pressure tested immediately after pressing.
PEX Press uses an attached stainless‑steel sleeve and press tool to create a consistent connection in seconds, reducing installation time and eliminating loose components found in other systems.
Yes. SharkBite PEX Press is tested beyond industry standards and is suitable for demanding residential and commercial plumbing applications.
Installation guides, technical specifications, and product documentation are available in the Resources section below and on individual product pages.
